Cargo drone

based on UL/LSA 600kg fixed wing plane

Engine

Manufacturer Rotax
Model 912
Horsepower 80 hp – 115 hp

Weight

Empty weight 330 kg
Max. Take-off weight 600 kg UL2 / LSA
Min. crew weight 0 kg
Max. crew weight 0 kg
Max. cargo weight 200 kg

Performance

Takeoff 150 m / 490 ft
Climb Rate 5–7 m/s / 1200 ft/min
Max Operating Altitude 5400 m / 18000 ft
Stall Speed with Flaps 53 km/h / 29 kt
Max Cruise Speed 250 km/h / 135 kt
Landing Groundroll 150 m /490 ft

Dimensions

Lenght 7,030 m
Height 2,650 m
Wing span 9,085 m
Wing area 10,757 m2
Horizontal tail width 2,800 m
Horizontal tail area 2,244 m2
Vertical tail area 1,116 m2
Cabin width 1,164 m
SOPHISTICATED

AI UAV autopilot

  • autonomous flight according 3D track in WGS84 coordinates
  • autonomous flight according 2D track in WGS84 coordinates and altitude above the terrain
  • auto start from defined airfield (could be grass runway)
  • auto approach to the landing on specific runway (could be grass airfield)
  • autonomous landing on specific runway (could be grass, but has to have at least 1.0 km)

Flight Data

  • absolute plane position WGS84 | • relative plane position
  • airspeed | • vertical speed
  • altitudes: baro | satellite (above geoid) | radio/laser
  • engine data: temperatures | pressures | rpm | fuel level
  • compass bearing/heading
  • calculated wind (speed, direction)
  • side slip
  • angle of attack
  • – sence & avoid system (prevents collisions with static or flying objects) – telemetry with GCS (ground control station)
  • flying telemetry
  • (realtime data down and mission plan changes up)
  • video telemetry
  • cargo telemetry
